25kW HD Digital Radar The new Simrad Low Emission HD Digital 25kW radar system combine high performance open array scanners with a proven history of oceangoing reliability and the latest in digital signal processing. Experience unparalleled situational awareness, with exceptional detection of small or distant targets and minimised screen-clutter. Our new Low Emission 25 kW HD open array digital radar boasts exceptional detection of small or distant targets using our advanced Digital Signal Processing technology. Screen clutter in any weather is virtually eliminated, allowing a clear, accurate and easy to interpret image. The 25kW open array is ideal for larger motorboats 50ft+ in length.

• Back by popular demand – a high performance 25kW 7’ model
• New Array Radar available in September 2014.
• All new 25kW 7-foot model - great for vessels with limited space
• perfect with new Simrad NSO evo2 systems
• All models feature new Long-life magnetrons and brush-less motors
• All models have reduced emission levels that exceed 2015 regulatory changes and offer safer operation
• Compatible with all Simrad current radar displays: NSE, NSS, NSS evo2 and NSO evo2
• Meet tough IMO IEC62388 Annex D target detection specifications and triggers RACONS and SARTS at required 5nm range
• Commercial design with 100kt sustained windload rating
• Automatic Tune, Gain and Sea Clutter adjustments
• Automatic Harbour and Offshore modes
• Dual EBL/VRM and Dual Guard zones
• Radar overlay on charts and 10-target MARPA tracking with optional heading sensor
• iPad/Android tablet control with optional Go Free wireless module
• For 24V DC systems only

The H5000 instrument system is powered by a smart Central Processing Unit (CPU), capable of running three levels of software, Hydra, Hercules and Performance. Performance is specifically designed for larger yachts. In addition to the benefits of running a CPU delivered by Hydra, plus the racing features of Hercules, Performance introduces features to facilitate the monitoring of complex systems typical of larger yachts such as support for dual wind sensors. Additionally, the system provides support for dual rudders, including advanced features like rudder toe-in angle. Performance also monitors multiple daggerboards; port, starboard, centre and provides an active draught value (depth below the daggerboard). Further bespoke functionality delivered by Performance for sailing large yachts includes the tracking of ground wind speed and direction, Rate of Turn and enhanced polar performance targets. It is straightforward to set up and calibrate with the new H5000 web-browser interface, however complex the system.

Key Features

• Hercules spec plus: Performance is packed with all the powerful features of the Hydra and Hercules systems, adding unique functionality for larger racing yachts and Superyachts

• User Defined Functions: This intuitive system lets you define up to 16 user functions for the ultimate in configuration flexibility.

• Enhanced Sensor Support including Dual Wind: The Performance CPU introduces features for the monitoring of more complex systems typical of larger yachts including dual wind sensors, rudders and multiple daggerboards, Ground Wind speed and direction and Rate of Turn

• Ultra-fast ARM Processor: The CPU achieves processor speeds of up to 50 times that of its predecessor, for rapid calculation, real-time data and fast updates; each with the trademark B&G precision

• GoFree™ Wireless Technology: Expand functionality even further with third-party apps and stream data via GoFree, B&G’s powerful wireless solution to remotely view H5000 instrument data via your tablet or smartphone. Requires wireless module.

• Network compatible: H5000’s highly compatible network provides peace of mind and swift, seamless integration with other instruments and electronics across the B&G marine network including AIS, radar and chartplotters

• Browser-based set-up: The CPU features browser-based setup via the new H5000 interface for fast, efficient and hassle-free commissioning and calibration
