VHF STACIONĀRĀS & ROKAS

Lihtne paigaldada, 2 värvi valikut, pööratud LCD öö reziim.

B&G V20S fixed mount class D DSC VHF radio: Entry level VHF radio with NMEA2000 connectivity for GPS position, backlight control and night mode grouping with B&G MFD’s. Built in GPS. Conforms to new 2018 EU Standards.

The Cortex H1 Tethered Handset is the voice and calling interface used for VHF and DSC calls. The handset’s touchscreen display is the primary interface together with dedicated buttons and the Click-Wheel for swift navigation, ease of operation and single-handed use. The touchscreen is purpose-built for the harsh marine environment and is designed and manufactured for use in wet conditions and with gloves. The handset provides a screen to set up and manage the Cortex M1 hub, view AIS target data and vessel instrumentation, manage and monitor alarms and configure the remote vessel monitoring. Upgrade your Cortex M1 SOTDMA smartAIS or add additional handsets for access to key functions in more places on board. Have situational awareness and VHF communication at your fingertips, no matter where you are on your boat. The Cortex H1 comes bundled in the Cortex V1 VHF. Add additional H1 handsets for additional stations. Includes an H1 Bulkhead Bonnector and an H1 Cradle. Operating Temperature: -25°C to +55°C (-13°F to 131°F); Audio: 3W Class D amplifier, THD < 5% @ 85dBA; Screen: LCD TFT Si, 640 x 800, 24bit Colour; Touch: Capacitive, optically bonded to LCD. Glove and salt water operable; Backlight: 600 cd/m2. Ambient light sensor for auto dimming.

The Cortex H1P Portable Handset is the voice and calling interface for VHF, DSC calls and to view AIS targets. The handset’s touchscreen display is the primary interface together with dedicated buttons and the Click-Wheel for swift navigation, ease of operation and single-handed use. The touchscreen is purpose-built for the harsh marine environment and is designed and manufactured for use in wet conditions and with gloves. The handset provides a screen to set up and manage the Cortex M1 hub, view AIS target data and vessel instrumentation, manage and monitor alarms and configure the remote vessel monitoring. Upgrade your Cortex M1 SOTDMA smartAIS or add additional handsets for access to key functions in more places on board. Have situational awareness and VHF communication at your fingertips, no matter where you are on your boat. Includes an H1P Charging Cradle and non-powered H1 cradle. Operating temperature: -25°C to +55°C (-13°F to 131°F); Audio: 3W Class D amplifier, THD < 5% @ 85dBA; Screen: LCD TFT Si, 640 x 800, 24bit Colour; Touch: Capacitive, optically bonded to LCD. Glove and salt water operable; Backlight: 600 cd/m2. Ambient li; Screen: LCD TFT Si, 640 x 800, 24bit Colour; Touch: Capacitive, optically bonded to LCD. Glove and salt water operable; Backlight: 600 cd/m2. Ambient light sensor for auto dimming.

Full Class B SOTDMA with smartAIS send and receive and integrated no-loss splitter. Monitor and control onboard systems and keep alerted on board or ashore from your smartphone. Operating Temperature: -25°C to +55°C (-13°F to 131°F); Supported Protocols: AIS Class B SO-TDMA, VHF Voice, Class D DSC, ATIS (user configurable, EU region), NOAA Weather (US region); Transmitter Frequency Error: Less than 300Hz; Antenna Connector: SO239; Splitter: Max input power 25W, Insertion Loss RX 0dB, TX < 1dB; Splitter Connector: BNC (2W).

Advanced multi-station VHF with intuitive touchscreen operation. Full Class B SOTDMA with smartAIS send and receive and integrated no-loss splitter. Monitor and control onboard systems and keep alerted on board or ashore from your smartphone. Includes M1 hub, tethered H1 handset and accessories; Built-in Class B SOTDMA with no-loss antenna splitter; Built-in WiFi and Cellular connectivity on monitoring on board and ashore; Low power consumption hub; 10Hz GPS antenna; 4-inch multi-touch display with gorilla glass for maximum durability; Single hand operation with click wheel and dedicated buttons; Wet and glove capable touchscreen; Optically bonded display for wide-angle and sunlight viewability, even in the harshest midday sun; 85 dBA of crystal-clear audio; Combined AIS and VHF display with voiced alerts; Touch a vessel onscreen for direct calling (DSC). Operating Temperature: -25°C to +55°C (-13°F to 131°F); Supported Protocols: AIS Class B SO-TDMA, VHF Voice, Class D DSC, ATIS (user configurable, EU region), NOAA Weather (US region); Transmitter Frequency Error: Less than 300Hz; Antenna Connector: SO239; Splitter: Max input power 25W, Insertion Loss RX 0dB, TX < 1dB; Splitter Connector: BNC (2W).

External Cellular Antenna connects using the Cellular Antenna Patch Cable (included) to the Cortex Hub. The External Cellular Antenna offers increased range over the internal antenna. Included Cellular Patch Cable is 5m (16ft) with Male SMA to Antenna and Female SMA to the Cortex Hub. Deck mount flush and Vertical surface mount included.

External GPS Antenna for Cortex M1 with 8" (200mm) cable. This multi-constellation GNSS Antenna is designed as an external antenna for the Cortex Hub, WatchMate Vision or XB series of AIS transponders . It is IP67 and UV stable for use in a harsh marine environment. GNSS (Global Navigation Satellite System) includes GPS, GLONASS, Bei Dou and Gallileo positioning networks.

The Cortex External Speaker is designed for the marine environment with an IP66 ingress protection the speaker is suitable for mounting almost anywhere on board. Compact in size, the speaker features a durable and UV stable polymer housing. Rated at 70W max power output (35W RMS) with a frequency response of 120Hz-20,000Hz to deliver a full clear sound for Cortex VHF voice and unique annunciated alarms. Surface Mount through using a 74.5mm (2 15/16”) diameter hole and requiring a minimum mounting depth of 56mm (2 1/4”). Mounted Outer Diameter: 93.5mm; Frequency Range: 120hz~20khz; Impedance: 4ohm; Watts: 70 Watt; Magnet Ferrite: 4oz; Woofer Material Polypropylene Cone; IP Rating: IP66; UV Stable: Yes; Pre-wired with 6.5ft / 1.98m of cable.

H1 Handset Bulkhead Connector includes a mounting base, cover, waterproof cap and power cable. Connect the bulkhead connector to 12V or 24V DC.

H1P Handset Charging Cradle securely holds a Cortex H1P Portable Handset. The cradle is pre-wired for connection to 12V or 24V DC. Small SMA connector for easy installation; Pre-wired 200mm (8”) RF cable for easy servicing; Two mounting confi gurations (deck or under deck); UV stable housing provides good color stability; UV stable plastic with a zinc plated alloy base; Dimensions: 60mm x 19mm; Loom: 200mm; Color: White; Mounting: Bulkhead, pole, deck and underdeck mounting.

New front mountable design for easy installation
New Industrial Design to align with style of Lowrance MFD’s
Seamless integration with a wider B&G system through NMEA 2000 and 0183
Built in AIS Receiver
Large screen with intuitive user interface

Railblaza Cradle Adapter fits to the rear of either the H1 Cradle or the H1P Charging Cradle allowing a Railblaza StarPort attachment to be connected.

HS35 juhtmevaba käsitoru, mis annab RS90 ja RS35 VHF raadiole täieliku mobiilsuse ja intercom side võimaluse.

Esimene Simradi VHF raadio, millel on sisse ehitatud B-klassi AIS vastuvõtja ja saatja ning GPS.

Põhiomadused:

•             B-klassi AIS saatja ja vastuvõtja

•             sisse ehitatud GPS

•             D-klassi DSC VHF raadio

•             NMEA 2000 ja 0183 ühilduvus

•             võimalik lisada kuni kaks HS40 juhtmevaba käsitoru

•             suur ekraan ja intuitiivne kasutajaliides

•             eemaldatav käsimikrofon

•             võimalik lisada väline kõlar või hailer

B&G V60 Replaces the current V50 mid level VHF, updated to comply with EN 301 025 (v2.2.1)
New front mountable design for easy installation
Low profile design to align with style of B&G MFD’s
Seamless integration with a wider B&G system through NMEA 2000 and 0183
Built in AIS Receiver
Large screen with intuitive user interface
Optional wireless handsеts with inductive charging

The V60-B includes a Class B AIS transmitter and receiver, which not only receives AIS targets but also transmits your yacht’s position to nearby AIS-equipped vessels. This helps other mariners to spot your boat through any conditions, day or night. A built-in AIS receiver monitors the position of other AIS-equipped vessels, helping you to proactively avoid collisions in crowded harbours and waterways. AIS information can be viewed on the radio’s built-in screen, or overlaid on your chart or radar screen through a compatible chartplotter.

Mount your handset anywhere on the boat with the non-powered handset cradle. The cradle has a two piece design hiding the mounting hardware behind the snap cover leaving you with a clean sleek design on the helm or bulkhead. The non-powered handset cradle can be used with either the H1(tethered) or H1P (portable) handsets.
